Amiga Video Hybrid Replacement 390229-03

$4.99 – $34.95

Used as a Digital to Analog Converter or DAC in the Amiga to convert the digital 12 bit video signal into analog signals to connect to a monitor.

  • Designed from original schematic
  • A500, A500+, A1000, A2000 and A3000 compatible
SKU: N/A Categories: , , Tags: , , , , , , , , , , , , , , , , , , , , , , ,

Used as a Digital to Analog Converter or DAC in the Amiga to convert the digital 12 bit video signal into analog signals to connect to a monitor.

  • Designed from original schematic
  • A500, A500+, A1000, A2000 and A3000 compatible

Weight 4 oz
Dimensions 1 × 3 × 1 in
DIY Kit

Yes (You build it), No (Built by DIYCHRIS), Board Only

BOM

Qty Parts Value Description
1 Socket DIP14 Socket
1 C1 0.1uF Ceramic Capacitor
1 IC1 74LS02N Quad 2-input NOR gate
1 PCB PINHD-2X17 PIN HEADER (Female)
1 PCB_PWR PINHD-1X4 PIN HEADER (Female)
1 PC_DRIVE PINHD-2X17 PIN HEADER (Male)
1 DRV_PWR PINHD-1X4 PIN HEADER (Male)
